1JZ/2JZ spring compressor
por MaartenO159
1
Descargas
9
Likes
0
Makes
Spring compressor for 1jz and 2jz engines. Used this on my 1jz-gte vvti I'm assuming other JZ engines have the same pattern.
You can use the original bolts that hold camshaft cap in place.
I printed mine out of regular PLA and it held up no problem. (ran out of orange halfway)
Drill out the hole with an 8.5mm drill.
Add 2 M8 nuts in the bottom.
I do advise to add a thin piece of metal to the top to prevent plastic chipping and getting into the head.
You can use the original bolts that hold camshaft cap in place.
I printed mine out of regular PLA and it held up no problem. (ran out of orange halfway)
Drill out the hole with an 8.5mm drill.
Add 2 M8 nuts in the bottom.
I do advise to add a thin piece of metal to the top to prevent plastic chipping and getting into the head.
