OLED display case with room for jogwheel and Micro SDRAMPS
by NilsR
14
Downloads
14
Likes
0
Makes
Update: Knob added. It should fit on an ALPS encoder with a 6mm shaft.
My 20x4 LCD display broke, so I ordered a new one. This time I decided to order an OLED display, because it looks cool.
I was fed up with the way I had a separate jogwheel, SDRAMPS and display. I decided to cram it all into a single, new box. The OLED display is a little thinner than the LCD, and I felt it needed a little protection. A piece of Plexiglas cut to 84mmx32mm can be mounted in front of the display module.
My 20x4 LCD display broke, so I ordered a new one. This time I decided to order an OLED display, because it looks cool.
I was fed up with the way I had a separate jogwheel, SDRAMPS and display. I decided to cram it all into a single, new box. The OLED display is a little thinner than the LCD, and I felt it needed a little protection. A piece of Plexiglas cut to 84mmx32mm can be mounted in front of the display module.
