Compact Fitting Socket for Dry Box
by TrocheHole
2.4k
Downloads
969
Likes
1.5k
Makes
Compact sockets for PTFE tube fittings with a filament guide for use in a dry box.In addition, optional parts (red ones in the picture) can be used to add angles. Compatible with 3 Types of FittingsPC4-01 (1/8)─ *Similar to M10, but different. The screw diameter is about 9.5 mm.PC4-M6PC4-M10 Bill of MaterialsPTFE Tube Fitting ─ x1M3 Hex Nut (or Tap Processing) ─ ×2M3 Screw─ [0° mount] 8mm or more ×2─ [20° mount] 15mm or more ×2─ [30° mount] 18mm or more ×2─ [40° mount] 22mm or more ×2 Boost MeIf
