Component Test Adapter

371 Download
258 Likes
1 Makes
Vai al Modello
For years I've been testing two-lead components using alligator clips, paperclips, gripping them with my fingers to the test probes, etc....
ENOUGH!!!
Here's a slick little build that you can quickly clip your test probes into when measuring two-lead components (I'm usually measuring thermistor output, resistors, testing capacitors, sensors, etc.).
I had all the parts on hand but nothing is too expensive or hard to get. I've included a bill of materials....
Fonte
Thingiverse
Cosa serve per stampare: Principiante Bassa affidabilità
Pezzo unico
Supporti 1/3
Assemblaggio 0/3
Impostazioni 1/3
Dimensioni piano 0/3
Post-lavorazione 0/3
Stampante
FDM / FFF
Formato file
STL
Materiale
TPU
Software
Cura, PrusaSlicer o simile
