Case for MiniITX Motherboard + ITX GPU card. ITX Tower M3
Pcie riser you can be use two variant: standart = 30cm or reverse version 21cm (https://aliexpress.ru/item/1005001856153964.html).
I am using reverse riser 21cm from metalfish s3 case.
Case support 120mmx2 low profile 15-17mm height fan, or 120mm(front)+92mm(up) low profile fan.
cpu cooler height support up to 60mm.
GPU lenght up to 190mm.
FR_Panel is a big detail, divided into two parts:FR_Panel_DN1 + FR_Panel_UP1
FR_Panel print with support without raft and XY distanse 1mm for better result at PLA.
Other panels print from PETG.
No need support for: fr_up_cooler_mount and Back_down_panel
Need print multiple:
LR_panel x2
pcie_stand x2
pad x4 from TPU
LR_panel_cutting.svg for laser cutting Left and right panel.
Build case at UNC-6/32 screw. And M3 din 912 16mm and 20mm screw.
For mount FR_Panel use M3-30mm
Pcie riser you can be use two variant: standart = 30cm or reverse version 21cm (https://aliexpress.ru/item/1005001856153964.html).
I am using reverse riser 21cm from metalfish s3 case.
Case support 120mmx2 low profile 15-17mm height fan, or 120mm(front)+92mm(up) low profile fan.
cpu cooler height support up to 60mm.
GPU lenght up to 190mm.
FR_Panel is a big detail, divided into two parts:FR_Panel_DN1 + FR_Panel_UP1
FR_Panel print with support without raft and XY distanse 1mm for better result at PLA.
Other panels print from PETG.
No need support for: fr_up_cooler_mount and Back_down_panel
Need print multiple:
LR_panel x2
pcie_stand x2
pad x4 from TPU
LR_panel_cutting.svg for laser cutting Left and right panel.
Build case at UNC-6/32 screw. And M3 din 912 16mm and 20mm screw.
For mount FR_Panel use M3-30mm
