Lithophane Lamp

This is a Lithophane lamp I designed for a buddy's bar. He is a Renegade Pig. It takes a panel roughly 150mm x 115mm. Print the lamp and then measure the inside opening to get the exact size based on what your printer produces. The panel is supposed to be friction fit. I lined the inside of mine with aluminium foil to help reflect more light to the panel. (Not sure if it helped or not but I did it anyway.) I also color printed the picture used for the lithophane and glued it to the back of the panel.To get the lamp to work I used the following parts and hot glued them inside. There is a recess for the LED:1 Watt Cool White LED - Heatsink Mounted: https://www.adafruit.com/product/518USB Micro-B Breakout Board: https://www.adafruit.com/product/1833I used a 27ohm resistor based on using the above parts from adafruit.Otherwise use a resistor of appropriate value (Use http://ledcalc.com with the parameters from your sourced LED, voltage source @ 5V). Make sure your circuit doesn't go over t
