smart Clock
by Ebonix
0
Downloads
0
Likes
0
Makes
This is a smart clock which gives time and weather.
The columns and colors indicate the temperature over a 32h time period (1 column = 1h) and the weather logo shows the trend at +4 & +12h.
UPDATE:
The program now propperly displays the weather types
UPDATE Feb. 5th 2025: Change from time API request to NTP request as the API server went down.
----------------------
BOM:
1x Adafruit Matrix Portal - CircuitPython Powered Internet Display
1x Medium 16x32 RGB LED matrix panel - 6mm Pitch (bought mine on Adafruit)
1x Motion sensor (generic)
1x Black LED Diffusion Acrylic Panel - 10.2" x 5.1" - 0.1" / 2.6mm thick (bought mine on Adafruit)
1x Clear Adhesive Squares - 6 pack - UGlu Dashes
4 M4 screw
5 self taping screw, 3mm diameter
--------------------
Assembly:
- Trim the back of the LED matrix, there is two small plastic extrusion to cut.
- Bolt the base to the LED matrix via the M4 screws
- Prepare the Matrix Portal as indicated here: https://learn.adafruit.com/adafruit-matrixportal-
