Stator Generator
9
Downloads
11
Likes
0
Makes
This is a .scad file to generate a stator, the part that holds the copper windings for a DIY electric motor. It has 7 parameters.
The shape is a central collar (the difference of two cylinders, i.e. a thick washer) union a number of poles ("T" shapes which are the union of two rectangular prisms) which are rotated evenly around the central collar, which is then intersected with an encompassing, large cylinder.
This was modified, simplified, commented, and updated from r0gueSch0lar's 2013 file.
Jackson Walters
The shape is a central collar (the difference of two cylinders, i.e. a thick washer) union a number of poles ("T" shapes which are the union of two rectangular prisms) which are rotated evenly around the central collar, which is then intersected with an encompassing, large cylinder.
This was modified, simplified, commented, and updated from r0gueSch0lar's 2013 file.
Jackson Walters
