Trimlbe TS7 Pole Mounted Quick Release

This is a Quick Release Pole Mount designed for a Trimble TS7. The retail price on the market for these was well over $200 dollars so I decided to make my own. The full cost of this including filament couldn't have been more than $25 dollars. Unfortunately the bracket isn't included in this model but if you just need a spare pole mount this is probably a suitable alternative. A few small metal parts are required for this build. They are:

1 x 7/16" Bolt (1.5 inches long)
1 x 7/16" Jam Nut
1 x 7/16" Nut
1 x 1/4" Bolt (1 inch long)
1 x 1/4" Nut
10 x 6-32 Machine Screws (0.5 inches long)
2 x [.36 X .032] Compression Springs (1 inch long)

For best results, I would recommend printing all parts in the orientations shown with 100% infill. The extra strength is needed to prevent flexing since the TS7 is so heavy. If you have issues with print quality rotating the parts might help, but I found these orientations to work the best. My prints were in PETG but any other filament would p
